Semiautomatic and Fully Automatic configuration
Waveform: ZOLL Rectilinear Biphasic™
Defibrillator Charge Hold Time: 30 seconds; ZOLL AED 3 Automatic model: 3 seconds prior to automatic shock delivery
Energy Selection: Factory preprogrammed selection (Adult: 120 J, 150 J, 200 J; Child: 50 J, 70 J, 85 J)
Patient Safety: All patient connections are electrically isolated
Charge Time: Less than 10 seconds with new battery
Pre-shock Pause: Less than 5 seconds (semi-automatic) and less than 8 seconds (automatic) with new battery
Electrodes: ZOLL CPR Uni-padz™
Self-test: Configurable automatic self-test every day or every 7 days. Default: every 7 days.
Monthly full-energy test (200 J).
Automatic Self-test Checks: Battery capacity, status, and expiry; electrode connection and expiry; ECG and charge/discharge circuits; microprocessor hardware and software; CPR circuitry and pads sensor; audio circuitry Compression Depth: 1.9 cm to 10.2 cm; 0.75 in to 4 in Defibrillation Advisory:
Evaluates defibrillation pad connection and patient ECG to determine if defibrillation is required.
Shockable Rhythms: Ventricular fibrillation with average amplitude >100 microvolts and wide complex ventricular tachycardia with rates greater than 150 BPM for adults, 200 BPM for paediatrics. For ECG analysis algorithm sensitivity and specificity, refer to ZOLL AED 3 Patient Impedance
Measurement Range: 10 to 300 ohms
Defibrillator: Protected ECG circuitry
Display Format: High-resolution LCD with capacitive touch panel
Display Screen Size: 5.39 cm x 9.5 cm; 2.12 in x 3.74
Data Recording and Storage: User-configurable for 1 or 2 clinical events for total of 120 minutes. Includes ECG, impedance measurements, device prompts and CPR data.
Data Recovery: Controlled by touchscreen, uploaded to USB memory stick, or ZOLL Case
Review™ over a Wi-Fi network Internal Clock Synchronisation: Coordinated Universal Time (UTC) synchronisation occurs when communicating with the ZOLL Online server.
Device Size: (H x W x D) 12.7 cm x 23.6 cm x 24.7 cm; 5.0 in x 9.3 in x 9.7 in Weight: 2.5 kg; 5.5 lbs (with battery)
Power: Battery Wireless: 802.11 a/b/g/n
Security Protocols: WPA 1, WPA 2, WPA Personal, WPA Enterprise Port: USB 2.0
Rescue Accessory Pack Contents: Non-latex gloves, a CPR barrier mask, razor, paper towel, and towelette.
Device Classification: Class II and internally powered per EN60601-1
Design Standards: Meets applicable requirements of EN 60601-1, IEC 60601- 1-11, IEC 60601-2-4
Environmental Operating Temperature: 0° to 50°C; 32° to 122°F
Storage Temperature: -30° to 70°C; -22° to 158°F
Battery Shelf Life: Store for up to 2 years at 23°C (77°F) prior to installing in ZOLL AED 3 to maintain above battery life.
